Description
EATON TP48-3-N-NDI
EATON TP48-3-N
General specifications
| Product Name |
Eaton Crouse-Hinds series MTL TP48 surge protector
|
| Product Name |
Eaton Crouse-Hinds series MTL TP48 surge protector
|
| Catalog Number |
TP48-3-N-NDI
|
| Product Length/Depth |
75 mm
|
| Product Height |
27 mm
|
| Product Width |
23 mm
|
| Product Weight |
175 g
|
| Global Catalog |
TP48-3-N-NDI
|
| Product Type |
Surge protector
|
Product specifications
| Area classification |
Hazardous/Classified Locations
|
| Standards type |
NEC/CEC
IEC IECEx/ATEX |
| IECEx/ATEX hazardous rating |
Zone 2
|
| Ingress protection (IP) ratings |
IP66
|
| Material |
316 stainless steel
|
| Type |
Certified
|
| Frequency |
1 MHz
|
| Thread Size |
1/2″ NPT
|
| Category Tested Acc. IEC 61643-21 |
A2, B2, C1, C2, C3, D1
|
| Connection Details |
4 flying leads (+ve, -ve, signal and earth)
|
| Conductor Cross-section AWG |
18 AWG
|
| Minimum Ambient Operating Temperature |
-40 °C
|
| Maximum Ambient Operating Temperature |
60 °C
|
| Minimum Ambient Storage Temperature |
-40 °C
|
| Maximum Ambient Storage Temperature |
85 °C
|
| Humidity |
5-95% RH (non-condensing)
|
| Modes of Protection |
Safeguards electronic process transmitters against induced surges and transients from field cabling
|
| Nominal Voltage DC |
35V
|
| Nominal Discharge Surge Current (8/20) |
10 kA
|
| Lightning Impulse Current (10/350 µs) |
2.5 kA
|
| Voltage Protection Level at In |
90V
|
| Voltage Protection Level at 1kV/µS |
<76V
|
| Max. Leakage Current |
<1μA
|
| Max. Continuous Voltage DC |
58V
|
| IEC |
IEC 61508
IEC 61511 |
TP48-N Non-certified SPD – 1/2” NPT thread
TP48-I Non-certified SPD – 20mm ISO thread
TP48-G Non-certified SPD – G 1/2” (BSP 1/2 inch)
TP48-3-N Non-certified SPD – 1/2” NPT thread
TP48-3-I Non-certified SPD – 20mm ISO thread
TP48-3-G Non-certified SPD – G 1/2” BSP 1/2 inch
TP48-4-N Non-certified SPD – 1/2” NPT thread
TP48-4-I Non-certified SPD – 20mm ISO thread
TP48-4-G Non-certified SPD – G 1/2” BSP 1/2 inch
TP48-N-NDI Certified SPD – 1/2” NPT thread
TP48-I-NDI Certified SPD – 20mm ISO thread
TP48-G-NDI Certified SPD – G 1/2” (BSP 1/2 inch)
TP48-3-N-NDI Certified SPD – 1/2” NPT thread
TP48-3-I-NDI Certified SPD – 20mm ISO thread
TP48-3-G-NDI Certified SPD – 20mm ISO thread
TP48-4-N-NDI Certified SPD – 1/2” NPT thread
TP48-4-I-NDI Certified SPD – 20mm ISO thread
TP48-4-G-NDI Certified SPD – G 1/2” – BSP 1/2 inch
